Technical Data
CompareDisinfection
| Measuring Principle | Free chlorine |
| Application | Water, Waste water, pools |
| Characteristic | Amperometric measurement of free chlorine. |
| Measuring range | 0,05 - 20ppm free chlorine; pH 4-8,2 |
| Measuring principle | - closed (membrane covered) measuring cell. - Reduction of Hypochloric acid (HOCl) to Chlorid on the cathode with a fixed voltage of 20mV. |
| Design | Closed amperometric 2-electrode sensor with PTFE-membrane. |
| Material | Sensor shaft : PVC Membrane : PTFE Membrane cap : PBT (GF30); PVDF |
| Dimension | Diameter : appr. 25mm Length : 160mm |
| Process temperature | 10°C - 45°C |
| Process pressure | 0bar - 1bar |
| Temperature sensor | Optional with NTC-temperature sensor |
| Connection | Fixed cable connection |
The CCS140 analog sensor is used for standard measurement of free chlorine. Even when flow or conductivity fluctuates, it transmits reliable measured values, controls the disinfection loop and ensures bacteria-free water. Long calibration and maintenance intervals also reduce maintenance costs.
Benefits
-
Recalibration interval of about 1-4 months under constant operating conditions
-
Pre-fitted membrane cap for easy membrane replacement
-
Measured value unaffected by fluctuations in medium conductivity
-
Measurement is independent of flow at flow rates above 30 l/h
-
No zero-point calibration required. There is also no need to install complex activated carbon filters as with open free chlorine sensors
Application areas
The CCS140 measures free chlorine in the following areas:
-
Industrial process water
-
- Process applications such as bottle washing machines
-
Wastewater treatment plant
-
- Reuse of treated wastewater
-
Utilities
-
- Disinfection of all measuring points
-
Swimming pool water
Spare Parts & Accessories 12
12 spare parts · click to expand
| Order code | Description | |
|---|---|---|
| 71268479 | ***Kit CCSx4x/142D: 测量腔 | Enquire |
| 71268482 | ***CCSx4x/142D备件：密封件 x2 | Enquire |
| 50005255 | ***覆膜替换件2 pcs., ready made for CCS 140/141/240/241 | Enquire |
| 50005256 | ***电解液50 ml, for CCS 140/141 | Enquire |
| 71076921 | ***维护包 CCS14xContent: Electrolyte 50ml / 1,69 fl.oz.; 2 membrane caps polish foil (2 qualities) | Details |
| 50005181 | 接线盒VBCFor extension of CMK measuring cable Protection class: IP65 | Enquire |
| 50001041 | ***DO/氯传感器零电标定粉末Chemical producing water free of oxygen or chlorine for test purposes. | Enquire |
| 50085333 | ***测量电缆For pH-/Redox electrodes or 2-electrode conductivity cells/ 2-electode amperometric cells with temperature sensor. Price per meter (minimum length 5 m). | Enquire |
| 71257946 | 手持式DPD比色法标定仪PF-3colorimetric measurement of free and total chlorine 0,05 - 6mg/l Disinfection, drinking and process water hand held photometer, IP67-graded, with cuvettes, DPD, according to ISO 7393 delivery in plastic case, test kit for free and total chlorine included hand-held photometer for calibration and verification of disinfection loops | Enquire |
| COY8- | 零点凝胶 COY8Zero point: Verification, calibration, adjustment at zero point of oxygen and disinfection sensors ::Amperometric and optical sensors ::12, 25 and 40mm diameter ::Application in the lab, in the field | Enquire |
| COY8- | 零点凝胶 COY8Zero point: Verification, calibration, adjustment at zero point of oxygen and disinfection sensors ::Amperometric and optical sensors ::12, 25 and 40mm diameter ::Application in the lab, in the field | Enquire |
| COY8- | 零点凝胶 COY8Zero point: Verification, calibration, adjustment at zero point of oxygen and disinfection sensors ::Amperometric and optical sensors ::12, 25 and 40mm diameter ::Application in the lab, in the field | Enquire |
Configurator / Comparison
A
Source: public information from the Endress+Hauser website
Measuring principle video
Click to playManuals & Documents 12
All documents for this model12 documents · click to expand
CCS240/241 Operating Instructions English
CCS140/141 Operating Instructions English
Operating Instructions CCS240 / CCS241 English
Operating Instructions CCS140 / CCS141 English
Operating Instructions CCS 240 / CCS 241 English
Operating Instructions CCS 140 / CCS 141 English
技术资料 Liquisys M CCM223/253 Chinese
技术资料 CCS140 / CCS141 Chinese
技术资料 Liquisys M CCM223/253 Chinese
技术资料 CCS140 / CCS141 Chinese
Technical Information CCM 223/ English
Technical Information CCS140 and CCS141 English
Case Studies
Municipal Wastewater Treatment · sterilize — Application Case
Customer Profile
The typical setting in Municipal Wastewater Treatment is the inlet, biological and outlet stages of a municipal plant. The measuring point is sterilize; the focus is monitoring and controlling disinfectant dosing and efficacy.
Key Difficulties
Conditions are high solids and corrosive fractions, with large diurnal flow swings and, on top of that, effluent parameters drift and probes foul with sludge and biofilm, which a standard configuration cannot handle for long. The design therefore starts with matching monitoring points to the disinfection route (chlorine, UV, ozone).
Implementation
The scope ran through the analyser range: selecting as part of a complete water-analysis system. Technically it hinges on matching monitoring points to the disinfection route (chlorine, UV, ozone), and on these requirements: stable compliance with Grade 1A discharge limits and online data reporting.
Customer Benefit
In practice this means on-demand dosing, lowering both by-products and cost, which cut the workload on the site maintenance team.
Food & Beverage · sterilize — Application Case
Project Background
The project covers dosing, pasteurising, filling and CIP stages. The work centres on sterilize and the core task is monitoring and controlling disinfectant dosing and efficacy.
Operating Challenges
The medium and duty are characterised by syrups, dairy and beverages that scale easily, under strict hygienic requirements, and frequent cleaning demands instruments that withstand hot CIP/SIP caustic cycles. So sterilize cannot be specified generically — it calls for matching monitoring points to the disinfection route (chlorine, UV, ozone).
Solution
The Ainstru engineering team worked through the analyser range: selecting as part of a complete water-analysis system. The configuration involves matching monitoring points to the disinfection route (chlorine, UV, ozone), with these requirements in view: food-safety and hygienic design per 3-A / EHEDG.
Results
Since start-up the system has run steadily; the practical result is on-demand dosing, lowering both by-products and cost.
Chemical & Pharmaceutical · sterilize — Application Case
Project Overview
The site is reactors, metering vessels and finished-product tanks. The customer wanted sterilize properly configured on the existing plant, with the aim of monitoring and controlling disinfectant dosing and efficacy.
Technical Challenges
What actually causes trouble is highly corrosive media with solvents and crystallisation, partly in explosive atmospheres, and corrosion plus Ex protection shortens instrument life and makes downtime costly. All of this means the sterilize configuration has to involve matching monitoring points to the disinfection route (chlorine, UV, ozone).
Configuration
Supply and installation were organised through the analyser range: selecting as part of a complete water-analysis system. On site this meant matching monitoring points to the disinfection route (chlorine, UV, ozone), checked line by line against: Ex certification and GMP traceability of records.
Performance
After commissioning the outcome is on-demand dosing, lowering both by-products and cost, and the readings are now used for process tuning.
Power & Energy · sterilize — Application Case
Site Conditions
This is a Power & Energy customer whose plant is at boiler feedwater, turbine condensate and FGD/DeNOx systems. The main task was monitoring and controlling disinfectant dosing and efficacy.
The Problem
The difficulty lies in high temperature and pressure with both steam and saline water; at the same time drift under high temperature and pressure, with very costly unplanned outages. Specification therefore means matching monitoring points to the disinfection route (chlorine, UV, ozone).
What We Did
We took a analyser range approach — selecting as part of a complete water-analysis system. Delivery was built around matching monitoring points to the disinfection route (chlorine, UV, ozone), with point-by-point checks on: compliance with power-industry codes and unit availability targets.
Operating Outcome
In service the system performs as intended — on-demand dosing, lowering both by-products and cost, with routine maintenance falling noticeably.
