472105 DIQ/S 281-MOD

Dual IQ/System 281, universal controller to connect 1 digital IQ sensor with Modbus RTU and 2 relays, 100 ... 240 VAC
双IQ/System 281，通用控制器，可连接1个数字IQ传感器与Modbus RTU和2个继电器，100。。。240伏交流电

售价：

¥ 0.00

原价： ¥0.00

ꄑ关注：0

服务：现货现款･ 48小时快速处理･含税运。

数量： ꄷ ꄸ

产品详情

Universal monitor DIQ/S 281. The new system 281 – the digital and cost-efficient single parameter measuring point with proven IQ Sensor Net technology and IQ sensors for the standard parameters. Low-cost alternative to analog measuring points

The System 281 combines the known performance of analog products with the advantages of the digital IQ Sensor Net:

Proven and reliable IQ Sensor Net technology
100 % IQ Sensor Net look & feel
Versions with analog outputs, Modbus RTU and HART available
2 relays for alarm for main and secondary value
You can easily upgrade to DIQ/S 282/284, since IQ sensors can be retained
Free software updates with new features
Stable, robust and proven measuring technology

Measurement Parameters:

Matching digital IQ sensors for pH/ORP, conductivity, D.O., turbidity, suspended solids and sludge level (also as seawater version for corrosive media)

Models:

DIQ/S 281-CR2 with power supply via a wide range power supply unit (100-240VAC), 2 analog outputs (0/4-20 mA) and 2 relays
DIQ/S 281-CR2/24V with 24V power supply, 2 analog outputs (0/4-20 mA) and 2 relays
DIQ/S 281-MOD with a wide-range power supply unit (100-240VAC), MODBUS interface (RS 485) and 2 relays
DIQ/S 281-HART with a wide-range power supply unit (100-240VAC) and 2 relays

Made for many applications:

Once developed for wastewater the IQ Sensor Net is also successfully applied in drinking water applications and the process industry for many years. Try it yourself! Some examples:

With SensoLyt® 700 IQ for different pH ranges in drinking water
With VisoTurb^® 700 IQ, the turbidity sensor with ultrasonic cleaning in the wwtp outlet
With the calibration free dissolved oxygen sensor FDO® 700 IQ in the aeration basin
With TetraCon^® 700 IQ, the 4 electrode conductivity cell in the process industry
With the suspended solids sensor ViSolid^® 700 IQ with ultrasonic cleaning in the aeration basin of a wwtp with industrial wastewater
With IFL 700 IQ, the ultrasonic sensor for detailed presentation of sludge profile in the post-sedimentation

Controller	DIQ/S 281-CR2	DIQ/S 281-CR2/24V	DIQ/S 281-MOD	DIQ/S 281-HART
Order No.	472103	472104	472105	472106
detailed technical data see data sheet D1.09
Max. number of sensors	1
Connectable sensors	IQ sensors for pH/ORP, O₂, conductivity, turbidity, TSS or sludge level
Communication	2 x (0) 4–20 mA2 x relays		Modbus RTU 2 x relays	HART 2 x relays
Cable length sensor	100 m fixed cable
Max. total cable length	250 m
Power supply	Wide range mains converter (100-240VAC)	24V	Wide range mains converter (100-240VAC)
Connectable modules	DIQ/CHV (Cleaning Head Valve), DIQ/JB and MIQ/WL PS SET
